Note:

1.Circuits: 3~40

2.Applicable PC board thickness: 0.8~1.6mm

3.Current rating: 0.5A,AC,DC

4.Withstand voltage: 500V AC/min

5.Working Temperature: -25℃~+85℃

6.Insulation resistance: ≧800MΩ

7.Contact resistance: ≦20mΩ

8.Single Contact: Single Contact
